Loctite HD 14, pneumatic dual-cartridge 400 ml gun, 1:1, 2:1, 4:1, 10:1 mix ratios – 2-part adhesive dispenser
Product code: 2693825
Leave feedback on the product
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Related products
Secure purchase guarantee
Product description
The Loctite HD 14 pneumatic dual-cartridge 400 ml gun is a high-performance dispenser for two-component adhesives and sealants. Powered by compressed air, it delivers a steady, controlled bead and comfortable operation even with high-viscosity materials.
Benefits and unique features
- Smooth flow control via the integrated pressure regulator
- Supports common mix ratios: 1:1, 2:1, 4:1, 10:1
- Ergonomic handle – reduced hand fatigue in long shifts
- Stable, repeatable dispensing of high-viscosity materials
- Robust industrial build for workshop and production use
Properties & applications
- 400 ml dual cartridges: dispensing 2K adhesives and sealants in standard mix ratios
- Pneumatic drive: constant output and high repeatability
- Precise flow control: quick adjustment to material viscosity and bead width
- Manufacturing & service: assembly, repairs, bonding metals, plastics and composites
Technical data
| Parameter | Value |
|---|---|
| Cartridge capacity | 400 ml (dual) |
| Mix ratios | 1:1, 2:1, 4:1, 10:1 |
| Cylinder diameter | 100 mm |
| Max. working pressure | 6.8 bar |
| Max. supply pressure | 10 bar |
| Pressure control | Stepless (integrated valve) |
| Sound level | ~83 dB |
| Recommended operating temp. | +5 °C to +40 °C |
| Relative humidity (operation) | 30–80% RH (non-condensing) |
| Transport & storage temp. | 0 °C to +40 °C |
| Weight | ~2.5 kg (400 ml version) |
| Air connection | ¼" NPTF or BSPPF quick coupling (not included) |
Storage recommendations
Store in a dry, clean place at 0–40 °C. Protect the tool from moisture and dust. Disconnect the compressed-air supply before storage; do not store the tool under pressure.
Product safety
Manufacturer
Henkel Polska Sp. z o.o.
Domaniewska 41
02-672 Warszawa, Poland
Responsible person in the EU
Henkel Polska Sp. z o.o.
Domaniewska 41
02-672 Warszawa, Poland
