Orlen Oil Trafo EN insulating oil for transformers and switchgear, insulating properties, anti-oxidation, anti-corrosion, stability in electric field
Product code: QFS385E10q
Leave feedback on the product
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Select product variant:
Individual variants may differ in price
Secure purchase guarantee
Product description
Orlen Oil Trafo EN is a high-quality electrical insulating oil. It is used in transformers, current relays and other electrical devices where it is required to provide electrical insulation and cooling. The product has antioxidant and anti-corrosion properties. They do not contain toxic compounds, but they have high thermo-oxidative resistance. Orlen Oil Trafo EN is a non-inhibited oil.
Properties:
- High thermal stability: resistant to high temperatures, which allows for long-term use in devices operating in harsh conditions.
- High electrical insulation: Provides effective electrical insulation between device components, protecting them from surges and damage.
- Low viscosity: Facilitates the flow of oil in devices, which contributes to effective cooling.
- Good aging resistance: has a long service life, reducing replacement intervals and lowering operating costs.
- Low hygroscopicity: it does not absorb moisture from the environment, thanks to which it maintains its insulating properties for long-term use.
- Compatibility with sealing materials: Oil does not react with sealing materials used in electrical equipment, preventing oil leakage and equipment damage.
Usage:
- Ensuring electrical insulation in transformers
- Cooling of electrical devices
- Current Relays
- High-voltage equipment
Storage method:
- Keep in tight and clean containers
- Avoid moisture and direct sunlight
- Keep away from sources of ignition and hazardous substances
- Ensure storage room ventilation
Parameters:
|
Product Specifications |
|
|---|---|
| Density at 15°C |
0.872g/cm3 |
|
Density at 20°C |
0.87g/cm3 |
|
kinematic viscosity at 40°C |
9.9mm2/s |
|
Kinematic viscosity at -30°C |
1005mm2/s |
|
Flash point |
146°C |
|
Water content |
8mg/kg |
|
Pouring point |
-51°C |
|
Dialectic loss factor at 90°C |
0.0015 |
|
Surface tension |
44mN/m |
|
Oxidation resistance: 164h -total acidity -sediment content |
0.72 0.1 |
|
Gas stability in an electric field |
+7.0mm3/min |
|
PCA content |
<1% |
|
PCB content |
Not detectable mg/kg |
