TS488 XM pneumatic bead dispenser 600 ml 1:1, 4 kN thrust, 8 bar, reinforced nylon & aluminium frame
Product code: DP2K 600-01-400-101
Leave feedback on the product
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Secure purchase guarantee
Product description
The TS488 XM is a two-component pneumatic bead dispenser for 600 ml 1:1 cartridges, delivering up to 4 kN thrust and precise dispensing of medium-viscosity materials.
Advantages and Unique Features
- Air-operated plunger retraction
- One-hand pressure adjustment for quick flow control
- Anti-drip function prevents unwanted run-on
- Reinforced nylon handle & aluminium tube for long life
- Up to 2-year warranty for worry-free use
Properties and Applications
- Maximum thrust 4 kN: for medium-viscosity epoxies and adhesives
- Operating pressure up to 8 bar: consistent material flow
- Air consumption 40 l/min: efficient operation
- Cartridge capacity 600 ml (1:1): standard size for large applications
- Applications: bonding, crack repair, roofing, chemical anchoring, sealing, waterproofing
Technical Specifications
| Specification | Value |
|---|---|
| Weight | 2.5 kg |
| Cartridge holder length | 270 mm |
| Maximum thrust | 4 kN |
| Max. pneumatic pressure | 8 bar |
| Air consumption | 40 l/min |
| Handle material | reinforced nylon |
| Holder material | aluminium |
| Frame material | steel |
| Approvals | CE |
| Cartridge capacity | 600 ml (1:1) |
| Viscosity | medium |
| Color | black/grey/red |
| Nozzle dimension | Ø25 mm |
Storage Recommendations
Store in a dry place at 5 °C–25 °C, away from heat sources and direct sunlight.
Product safety
Manufacturer
medmix UK Ltd
1 Tealgate
RG17 0YT Hungerford, United Kingdom
Responsible person in the EU
Melkib Klus Raczek Spółka Komandytowa
ul. Stawowa 91
43-400 Cieszyn, Poland
