WEICON Mounting Tape grey 19 mm × 3 m – double-sided mounting tape 85 kg/m
Product code: 10052657
Leave feedback on the product
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Secure purchase guarantee
Product description
WEICON Mounting Tape grey 19 mm × 3 m – double-sided mounting tape 85 kg/m is a strong acrylic-foam double-sided tape for clean, drill-free mounting. It also performs on low-surface-energy plastics (PE/PP) and powder-coated surfaces. UV- and moisture-resistant for indoor and outdoor applications.
Why choose it
High adhesion on PE/PP • reliable bonding on powder-coated surfaces • UV and moisture resistance (outdoor) • elastic foam compensates stresses • fast, clean installation without drilling
Applications
Permanent mounting of trims, panels, profiles and covers in metalworking, automotive/van conversions, caravanning, electronics and PoS/display.
How to use
Clean and degrease both substrates; apply at a minimum of 15 °C; press down firmly and evenly along the full length. The bond reaches full strength after approx. 24 h.
Technical parameters
| Parameter | Value |
|---|---|
| Colour | Grey |
| Carrier | Modified acrylic foam |
| Width | 19 mm |
| Roll length | 3 m |
| Tape thickness | 0.9 mm |
| Linear load capacity | 85 kg/m |
| Elongation at break | 750 % |
| Tensile strength | 10 N/cm |
| Adhesion on steel | 20 N/cm |
| T-block strength (Al) | 50 N/cm |
| Dynamic shear strength | 45 N/cm² |
| Static shear strength | > 10 000 min |
| Time to full strength | approx. 24 h |
| Service temperature | −40 to +120 °C |
| Minimum application temperature | 15 °C |
| Manufacturer code | 14050319 |
Values according to the manufacturer’s technical data sheet; actual results depend on substrate preparation, pressure, time and joint geometry.
Storage
Store in the original, closed packaging in a dry, cool place, away from heat sources and direct sunlight. Protect the tape surface from dust and contamination.
FAQ
1) Double-sided tape for PE/PP — will this one work?
Yes. This version is recommended for low-surface-energy plastics (PE/PP). Proper degreasing and strong, even pressure are essential.
2) How much weight can mounting tape hold? How to estimate 85 kg/m?
The declared linear load is 85 kg per 1 m of 19 mm tape. As a rule of thumb, ~1 kg requires about 1.2 cm of tape length; in practice use at least 2× safety margin and distribute the load over a greater length.
3) Outdoor use — UV and moisture resistance?
Yes. Suitable for outdoor applications; service temperature −40 to +120 °C, UV- and moisture-resistant.
4) How long until full strength?
Approximately 24 h under typical conditions.
5) Best application temperature?
Apply at ≥ 15 °C; lower temperatures reduce initial tack.
6) Will it bond on powder-coated surfaces?
Yes, when properly prepared and degreased.
7) How to remove double-sided tape without damage?
Lift an edge and “roll” the tape off mechanically; gentle heating helps. Remove adhesive residues with a suitable remover after testing on the substrate.
