Medmix MFQX 07-24T green Quadro static mixer nozzle for 2K adhesives 490 ml, F-System 4:1 and 10:1, 24 elements, 7 mm, 137 mm

The green Medmix MFQX 07-24T 2K adhesive mixer is a Quadro static mixing nozzle designed for 490 ml F-System Mixpac cartridges with 4:1 and 10:1 mix ratios. The 24-element static mixer ensures a homogeneous adhesive blend and uniform bead dispensing. Thanks to its compact length of approx. 137 mm and outlet diameter of around 7 mm, it is ideal for precise yet highly efficient industrial applications.

Advantages and unique features

• Compatible with 490 ml 2K cartridges in the F-System Mixpac range.
• Supports two mix ratios – 4:1 and 10:1 – with a single mixer type.
• Twenty-four mixing elements provide intensive and repeatable mixing of components A and B.
• Stepped outlet tip allows the bead width to be adjusted by trimming the nozzle.
• Approx. 7 mm outlet diameter and 137 mm length make application on profiles, edges and wider surfaces easy.
• Single-use static mixer – no cleaning required and reduced risk of contamination inside the adhesive.

Properties and applications

• Mixing 2K adhesives and sealants: ensures correct combination of components in 4:1 and 10:1 cartridges and helps achieve the strength values specified by the adhesive manufacturer.
• Bead application: designed for uniform bead dispensing on frames, profiles, panels and other structural parts.
• F-System Mixpac interface: suitable for cartridges with the corresponding connection used in 490 ml 2K cartridge guns.
• Industrial bonding: for bonding metals, plastics and composites in automotive, machinery, window and door production and prefabrication.
• Repair and maintenance: ideal for workshops and maintenance departments where fast work and reliable mixing are crucial.

Technical data

Storage recommendations

Store Medmix MFQX 07-24T mixers in their original packaging in a dry, clean place away from direct sunlight and heat sources. Protect the nozzles from deformation and damage to the cartridge connection. Keep out of the reach of children and use only with compatible 2K cartridges according to the adhesive manufacturer’s instructions.

FAQ

1) Which cartridges are compatible with the Medmix MFQX 07-24T mixer?
The nozzle is intended for 490 ml 2K cartridges in the F-System Mixpac range with the appropriate connection.

2) Can a single mixer handle different mix ratios?
Yes, the MFQX 07-24T works with cartridges at 4:1 and 10:1 mix ratios, making it suitable for many 2K adhesive systems.

3) Why use a stepped tip?
The stepped tip can be trimmed at the desired step to adjust the outlet diameter and bead width to the application requirements.

4) Is the MFQX 07-24T mixer reusable?
No, it is a single-use static mixer. Once the adhesive has cured inside the mixing channel, a new nozzle must be used to maintain mixing quality and cleanliness.
