Manual gun for 1-component 310 mL cartridges, 26:1 ratio, 5 kN thrust, anti-drip, reinforced nylon — for high-viscosity materials
Product code: DM1K 310-CA-R26-001
Leave feedback on the product
Shipping cost for the selected product
The shipping cost applies to this product (in the selected variant - if applicable). It may change after adding other products to the cart.
Related products
Secure purchase guarantee
Product description
The manual gun for 1-component 310 mL cartridges is a robust, lightweight dispenser for high-viscosity adhesives and sealants. A reinforced plastic frame and a 26:1 ratio deliver up to 5 kN thrust and clean, precise dispensing for bonding, sealing and chemical anchoring.
Benefits and unique features
- Anti-drip with trigger brake release — stops ooze when the trigger is released
- 26:1 mechanical advantage and up to 5 kN thrust — easier work with thick materials
- Adjustment screw extends mechanism life
- Reinforced nylon frame — stiff yet light
- Quick cartridge snap-fit and automatic positioning
Properties and applications
- Applications: bonding, sealing, chemical anchoring
- Viscosity range: high
- Pack type: 1-component cartridge, 310 mL
Technical parameters
| Parameter | Value |
|---|---|
| Tool weight | approx. 0.8 kg |
| Barrel length | 250 mm |
| Maximum thrust | 5 kN (plunger stroke ~3.5 mm) |
| Mechanical advantage | 26:1 |
| Cartridge capacity | 310 mL (1-component) |
| Material viscosity | high |
| Handle material | reinforced nylon (moulded) |
| Barrel material | reinforced nylon (moulded) |
| Standard colour | black |
| Nozzle cap diameter | Ø 30 mm |
Dimensions of compatible 1-component cartridges
| Cartridge type | Volume | Length l | Diameter a |
|---|---|---|---|
| Single-component cartridge | 310 mL | 216 mm (8.5") | Ø 48.2 mm (1.8") |
Storage recommendations
Store the gun in a clean, dry place away from heat and UV. After use, release the adjustment screw and clean parts in contact with material. Do not leave a loaded cartridge in the tool for extended periods.
FAQ
1) What materials is it for?
High-viscosity adhesives and sealants in 1-component 310 mL cartridges.
2) Does it have anti-drip?
Yes — releasing the trigger activates the brake and stops flow.
3) Why a 26:1 ratio?
Higher force with less effort and better control of thick products.
4) What is the body made from?
Reinforced nylon — lightweight and wear-resistant.
5) Any maintenance tips?
Keep the barrel and plunger clean; use the adjustment screw to reduce wear.
